GENERAL INFO

COLOR:

WHEEL SIZE:

20" wheels

SPEEDS:

1 x 8

WEIGHT:

25.4 kg (55.9 lb)

FOLDING SIZE:

163 x 40.5 x 86 cm (64" x 15.9" x 34")

FOLDING TIME:

5 sec

FRAME SIZES:

One size

GEAR INCHES:

31" - 95" (2.47 - 7.56 m)

DISTANCE: SEATPOST TO HANDLEBAR:

Min: 490 mm (19.3"); Max: 590 mm (23")

DISTANCE: SADDLE TO PEDAL:

Min: 690 mm (27.2") Max: 1050 mm (41.3")

SUGGESTED RIDER HEIGHT:

150 - 195 cm (4'11" - 6'5")

MAX GROSS VEHICLE WEIGHT:

170 kg (374 lbs)

MAX RIDER WEIGHT:

120 kg. (264 lbs.)

FRAME

FRAME:

Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg

FORK:

Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE tested for 170 kg

COCKPIT

HANDLEPOST:

Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm

STEM:

Tern Andros (G2), adjustable, forged construction, patented technology

HEADSET:

Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated

HANDLEBAR:

Tern Sweep, 6061-AL, Tern Andros adapted

GRIPS/BAR TAPE:

Ergon

SADDLE:

Tern HSD

SEATPOST:

Tern Telescope, 34.9/30.9 mm, 2014-AL

SEATPOST CLAMP:

Tern Collar, 6061-AL, 2pc

BRAKES

FRONT BRAKE:

Magura MT4, hydraulic disc, 180 mm rotor

REAR BRAKE:

Magura MT4, hydraulic disc, 160 mm rotor

BRAKE LEVERS:

Magura, hydraulic

BRAKE CABLE & HOUSING:

Magura, hydraulic

WHEELS

FRONT WHEEL:

Tern Atlas H, cargo wheel

REAR WHEEL:

Tern Atlas H, cargo wheel

FRONT HUB:

Novatec, Thru-axle, sealed bearings

REAR HUB:

Shimano Nexus 8

SPOKES AND NIPPLES:

Stainless steel

RIMS:

Tern Atlas H, wide 35 mm

TIRES:

Schwalbe Big Ben, 55-406, RaceGuard puncture protection, ECE-R75 ebike certification

TRANSMISSION

SHIFTER(S):

Shimano Nexus 8

CRANKSET:

Tern HSD custom, Gates CDX CNC machined beltring

CASSETTE/FREEWHEEL:

Gates CDX, precision CNC machined cog

BOTTOM BRACKET:

Motor integrated

CHAIN:

Gates Carbon Drive CDX belt

PEDALS:

Urban with non-slip surface

SHIFTER CABLE & HOUSING:

Shimano

E-SYSTEM

MOTOR:

Bosch Active Line Plus (Gen 3), max speed 25 kph (EU); max speed 20 mph (US)

BATTERY:

Bosch PowerPack 400

DISPLAY:

Bosch Purion, 4 mode selectable, walk assist

RANGE:

42 -110 km (26-69 mi)

CHARGER:

Bosch Standard Charger

BELLS & WHISTLES

BELL:

Aluminum

CHAINGUARD:

Gates integrated

KICKSTAND:

Ursus, rear mount

LUGGAGE SOCKET:

Combo Mount

FRONT LIGHT:

Tern Valo Direct, 45 lux/190 lumens

REAR LIGHT:

Herrmans H-Trace, for eBike

FENDERS:

SKS, stainless hardware

RACK(S):

Atlas H rack, Atlas Rack Mount, 6 point mounting, max load capacity 60 kg (132 lb)

ACCESSORY:

ABUS 5650L, keyed-alike with Bosch battery

*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.

‍

GENERAL INFO

COLOR:

WHEEL SIZE:

20" wheels

SPEEDS:

∞/9 spd manual

WEIGHT:

26.7 kg (58.7 lb)

FOLDING SIZE:

163 x 40.5 x 86 cm (64" x 15.9" x 34")

FOLDING TIME:

5 sec

FRAME SIZES:

One size

GEAR INCHES:

29" - 111" (2.34 - 8.89 m)

DISTANCE: SEATPOST TO HANDLEBAR:

Min: 490 mm (19.3"); Max: 590 mm (22")

DISTANCE: SADDLE TO PEDAL:

Min: 690 mm (27.2") Max: 1050 mm (41.3")

SUGGESTED RIDER HEIGHT:

150 - 195 cm (4'11" - 6'5")

MAX GROSS VEHICLE WEIGHT:

170 kg (374 lbs)

MAX RIDER WEIGHT:

120 kg. (264 lbs.)

FRAME

FRAME:

Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg

FORK:

Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE tested for 170 kg

COCKPIT

HANDLEPOST:

Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm

STEM:

Tern Andros (G2), adjustable, forged construction, patented technology

HEADSET:

Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated

HANDLEBAR:

Tern Sweep, 6061-AL, Tern Andros adapted

GRIPS/BAR TAPE:

Ergon

SADDLE:

Tern HSD

SEATPOST:

Cane Creek Thudbuster ST, Tern Telescope, 34.9/30.9 mm

SEATPOST CLAMP:

Tern Collar, 6061-AL, 2pc

BRAKES

FRONT BRAKE:

Magura MT4, hydraulic disc, 180 mm rotor

REAR BRAKE:

Magura MT4, hydraulic disc, 160 mm rotor

BRAKE LEVERS:

Magura, hydraulic

BRAKE CABLE & HOUSING:

Magura, hydraulic

WHEELS

FRONT WHEEL:

Tern Atlas H, cargo wheel

REAR WHEEL:

Tern Atlas H, cargo wheel

FRONT HUB:

Novatec, Thru-axle, sealed bearings

REAR HUB:

Integrated automatic shifting (more info soon)

SPOKES AND NIPPLES:

Stainless steel, double-butted

RIMS:

Tern Atlas H, wide 35 mm

TIRES:

Schwalbe Big Ben, 55-406, RaceGuard puncture protection, ECE-R75 ebike certification

TRANSMISSION

SHIFTER(S):

Enviolo AUTOMATiQ

CRANKSET:

Tern HSD custom, Gates CDX CNC machined beltring

CASSETTE/FREEWHEEL:

Gates CDX, precision CNC machined cog

BOTTOM BRACKET:

Motor integrated

CHAIN:

Gates Carbon Drive CDX belt

PEDALS:

Urban with non-slip surface, sealed bearings

E-SYSTEM

MOTOR:

Bosch Performance (Gen 3), max speed 25 kph (EU); max speed 20 mph (US)

BATTERY:

Bosch PowerPack 500

DISPLAY:

Bosch Intuvia, 4 mode selectable, walk assist, integrated auto/manual shifting

RANGE:

51-118 km (32-74 mi)

CHARGER:

Bosch Standard Charger

BELLS & WHISTLES

BELL:

Aluminum

CHAINGUARD:

Gates integrated

KICKSTAND:

Ursus, rear mount

LUGGAGE SOCKET:

Combo Mount

FRONT LIGHT:

Tern Valo Direct, 45 lux/190 lumens

REAR LIGHT:

Herrmans H-Trace, for eBike

FENDERS:

SKS, stainless hardware

RACK(S):

Atlas H rack, Atlas Rack Mount, 6 point mounting, max load capacity 60 kg (132 lb)

ACCESSORY:

ABUS 5650L, keyed-alike with Bosch battery

*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.

‍

GENERAL INFO

COLOR:

WHEEL SIZE:

20" wheels

SPEEDS:

1 x 9

WEIGHT:

25.7 kg (56.5 lb)

FOLDING SIZE:

163 x 40.5 x 86 cm (64" x 15.9" x 34")

FOLDING TIME:

5 sec

FRAME SIZES:

One size

GEAR INCHES:

33" - 97" (2.65 - 7.72 m)

DISTANCE: SEATPOST TO HANDLEBAR:

Min: 490 mm (19.3"); Max: 590 mm (23")

DISTANCE: SADDLE TO PEDAL:

Min: 690 mm (27.2") Max: 1050 mm (41.3")

SUGGESTED RIDER HEIGHT:

150 - 195 cm (4'11" - 6'5")

MAX GROSS VEHICLE WEIGHT:

170 kg (374 lbs)

MAX RIDER WEIGHT:

120 kg. (264 lbs.)

FRAME

FRAME:

Tern HSD, 6061-AL, patented design, Tern sliding dropouts, EFBE Tri-Test approved: 170 kg

FORK:

Suntour custom for Tern, Chromoly steerer, 32 mm stanchions, Thru-axle, EFBE tested for 170 kg

COCKPIT

HANDLEPOST:

Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm

STEM:

Tern Andros (G2), adjustable, forged construction, patented technology

HEADSET:

Tern Flux, cartridge bearings, Physis integrated

HANDLEBAR:

Tern Sweep, 6061-AL, Tern Andros adapted

GRIPS/BAR TAPE:

Ergon

SADDLE:

Tern HSD

SEATPOST:

Tern Telescope, 34.9/30.9 mm, 2014-AL

SEATPOST CLAMP:

Tern Collar, 6061-AL, 2pc

BRAKES

FRONT BRAKE:

Shimano, hydraulic disc, 180 mm rotor

REAR BRAKE:

Shimano, hydraulic disc, 160 mm rotor

BRAKE LEVERS:

Shimano, hydraulic disc

BRAKE CABLE & HOUSING:

Shimano, hydraulic disc

WHEELS

FRONT WHEEL:

Tern Atlas H, cargo wheel

REAR WHEEL:

Tern Atlas H, cargo wheel

FRONT HUB:

Novatec, Thru-axle, sealed bearings

REAR HUB:

Shimano disc

SPOKES AND NIPPLES:

Stainless steel

RIMS:

Tern Atlas H, wide 35 mm

TIRES:

Schwalbe Big Apple, 55-406, puncture protection, Reflex

TRANSMISSION

SHIFTER(S):

Shimano Alivio, 1 x 9 spd, trigger

REAR DERAILLEUR:

Shimano Alivio Shadow

CRANKSET:

Tern HSD custom

CASSETTE/FREEWHEEL:

Shimano 11-32T, 9 spd

BOTTOM BRACKET:

Motor integrated

CHAIN:

9 spd, DHT for eBike, GST corrosion resistant coating

PEDALS:

Urban with non-slip surface

SHIFTER CABLE & HOUSING:

Jagwire LEX-SL, slick treatment, alloy ferrules

E-SYSTEM

MOTOR:

Bosch Active Line Plus (Gen 3), max speed 25 kph (EU); max speed 20 mph (US)

BATTERY:

Bosch PowerPack 400

DISPLAY:

Bosch Purion, 4 mode selectable, walk assist

RANGE:

42 -110 km (26-69 mi)

CHARGER:

Bosch Compact Charger

BELLS & WHISTLES

BELL:

Aluminum

CHAINGUARD:

SKS Chainblade

KICKSTAND:

Ursus, rear mount

LUGGAGE SOCKET:

Tern Valo Direct, 45 lux/190 lumens

FRONT LIGHT:

Tern Valo Direct, 45 lux/190 lumens

REAR LIGHT:

Herrmans H-Trace, for eBike

FENDERS:

SKS, stainless hardware

RACK(S):

Atlas H rack, Atlas Rack Mount, 6 point mounting

ACCESSORY:

ABUS 5650L, keyed-alike with Bosch battery

*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.

‍
